Kepo MC 35 - Pellet Boiler (35 kW)
Other variants
- 35 kW output for large buildings and agricultural applications
- High efficiency and low emissions
- Manual heat exchanger cleaning for extended lifespan
- Automatic ignition and fuel dosing
- Compact, space-saving design
- Intuitive 4.3-inch colour touchscreen control
- Compatible with buffer tanks and hot water cylinders
Built for maximum heating capacity
The Kepo MC 35 is the most powerful model in the MC series, offering an impressive 35 kW output. Designed for high-demand projects such as large homes, commercial buildings and agricultural facilities, it uses advanced combustion technology to extract maximum energy from every pellet, ensuring high efficiency and low operating costs.
Reliable technology and long service life
The MC 35 features manual heat exchanger cleaning, which reduces wear, minimises the risk of malfunctions and extends the unit’s lifespan. Its robust steel construction and premium components make it ideal for intensive daily operation.
Ease of use for installer and end user
A 4.3-inch colour touchscreen makes it easy to adjust temperature settings, operating modes and weekly programmes. The intuitive control system provides clear feedback on performance.
Flexible installation options
With its compact, space-saving design, the MC 35 can be integrated into technical rooms, warehouses or other installation sites. It is compatible with various heating systems including radiators, underfloor heating and domestic hot water, and can be combined with buffer tanks and indirect water heaters for a complete heating setup.
An investment in reliable heating
Choosing the Kepo MC 35 means investing in a powerful, efficient and sustainable heating solution. Explore our full range of pellet boilers or contact Hewa for technical details, quotations and delivery options.
| Generals | |
|---|---|
| Item number | 020204 |
| EAN Code | 8721082877770 |
| Price excl. VAT | € 4.058,90 |
| Price incl. VAT | € 3.929,00 |
| Sizes ((LxWxH):) | 104 x 77 x 160 cm |
| Specification list | |
| Weight (kg) | 410 kg |
| Dimension (W×D×H) mm | 765x1040x1600 mm |
| Flue pipe diameter (Ø) | 120 mm |
| Pellet tank capacity (kg) | 120 kg |
| Power consumption at start on pellet (W) | 400 W |
| Power consumption in operation (W) | 115 W |
| Nominal voltage (VAC) | 220 - 240 VAC |
| Nominal frequency (Hz) | 50 Hz |
| Water pipe connection size | G 1 1/4" M |
| Safety valve pipe connection | G 1/2" F |
| Pump flow rate (L/h) | 1300 L/h |
| Boiler water volume (L) | 98 L |
| Boiler power (kW) | min 8.70– max 35.70 kW |
| Pellet consumption (kg/h) | min 2.10 – max 8.60 kg/h |
| Water temperature (°C) | min 60 – max 80 °C |
| Min. boiler water pressure (bar) | 0.6 bar |
| Max. boiler water pressure (bar) | 2.5 bar |
| Preferred pellet class | C1 - A1 |
| Boiler class | 5 |
| Energy efficiency | A+ |
| Suitable surface area (m²) | 170 - 330 m² |
| Fuel | Wood pellets |
| Subject | Action |
|---|---|
| How to clean a Kepo pellet boiler faq | View |
| How to replace the igniter of a Kepo pellet boiler faq | View |
| ER01 - Safety thermostat HV1 intervention Error code | View |
| ER02 - Safety pressure switch HV2 intervention Error code | View |
| ER03 - Shutdown due to decrease in flue gas temperature Error code | View |
| ER04 - Shutdown due to water overtemperature Error code | View |
| ER05 - Shutdown due to flue gas overtemperature Error code | View |
| ER07 - No encoder signal from combustion fan Error code | View |
| ER08 - Combustion fan speed regulation failed Error code | View |
| ER09 - Low water pressure Error code | View |
| ER10 - High water pressure Error code | View |
| ER11 - Incorrect time/date values after long absence of mains power Error code | View |
| ER12 - Ignition failed Error code | View |
| ER15 - Power supply fault Error code | View |
| ER16 - RS485 communication error Error code | View |
| ER17 - Air flow regulation failed Error code | View |
| ER18 - Lack of fuel Error code | View |
| ER23 - Boiler probe, boiler return probe, buffer tank probe, or low buffer tank probe open Error code | View |
| ER25 - Cleaning motor fault Error code | View |
| ER26 - Cleaning motor 2 fault Error code | View |
| ER27 - Cleaning motor 3 fault Error code | View |
| ER39 - Flowmeter sensor fault Error code | View |
| ER41 - Minimum air flow in Check Up not reached Error code | View |
| ER42 - Maximum air flow exceeded (FL40) Error code | View |
| ER44 - Door error Error code | View |
| ER47 - No encoder signal from auger Error code | View |
| ER48 - Auger speed regulation failed Error code | View |
| ER56 - Modified hydraulic plant Error code | View |
