Kepo AC 20 - Pellet Boiler (20 kW)
Other variants
- 20 kW capacity for medium-sized heating systems
- Automatic burner and heat exchanger cleaning
- High efficiency (>90%) and low emissions
- 4.3” touchscreen control
- Quiet, low-maintenance operation
- Optional WiFi and BigTank pellet storage
- Compatible with hybrid heating setups
Pellet heating for greater capacity needs
The Kepo AC 20 pellet boiler delivers a thermal output of 20 kW, making it ideal for medium-sized homes, commercial premises and buildings with higher heat demands. It combines eco-friendly heating from renewable wood pellets with advanced combustion technology and consistent performance.
Benefits for both installers and end users
Automatic cleaning of the burner and heat exchanger keeps efficiency levels high while minimising maintenance. The AC 20’s compact footprint and standard connections make installation straightforward in both new and retrofit projects. Installers benefit from excellent component accessibility, which simplifies servicing.
Advanced combustion control
The intelligent controller continuously adjusts pellet feed and air supply to match the actual heating demand. This ensures stable heat output, reduced fuel consumption and extended boiler life – all while maintaining optimal comfort.
Versatile integration options
The AC 20 can be combined with high-capacity buffer tanks, underfloor heating, radiators and hot water modules. It also supports integration into hybrid heating configurations with solar thermal systems or heat pumps. With the optional BigTank pellet storage (225 kg), refill intervals are significantly extended, which is particularly beneficial for larger systems.
Easy operation and comfort
The 4.3” colour touchscreen makes adjusting temperatures and programming schedules straightforward. With the optional WiFi module, remote control from a smartphone or tablet is possible. Its quiet operation means it can be installed near living or working areas without disruption.
Supported by Hewa
Hewa offers full support for both professional installers and private customers – from technical documentation to tailored delivery. We assist with system design, capacity calculations and integration with other sustainable heating solutions such as domestic hot water tanks.
Interested in the Kepo AC 20? Contact us today for a tailored quotation and expert advice.
| Generals | |
|---|---|
| Item number | 020102 |
| EAN Code | 8721082877121 |
| Price excl. VAT | € 3.511,40 |
| Price incl. VAT | € 3.399,00 |
| Sizes ((LxWxH):) | 83 x 67 x 128 cm |
| Specification list | |
| Weight (kg) | 255 kg |
| Dimension (W×D×H) mm | 670x830x1280 mm |
| Flue pipe diameter (Ø) | 80 mm |
| Pellet tank capacity (kg) | 62 kg |
| Power consumption at start on pellet (W) | 390 W |
| Power consumption in operation (W) | 110 W |
| Nominal voltage (VAC) | 220 - 240 VAC |
| Nominal frequency (Hz) | 50 Hz |
| Water pipe connection size | G 1" M |
| Safety valve pipe connection | G 1/2" F |
| Pump flow rate (L/h) | 1300 L/h |
| Boiler water volume (L) | 53 L |
| Boiler power (kW) | min 5.79 – max 18.50 kW |
| Pellet consumption (kg/h) | min 1.37 – max 4.56 kg/h |
| Water temperature (°C) | min 60 – max 80 °C |
| Min. boiler water pressure (bar) | 0.6 bar |
| Max. boiler water pressure (bar) | 2.5 bar |
| Preferred pellet class | C1 - A1 |
| Boiler class | 5 |
| Energy efficiency | A+ |
| Suitable surface area (m²) | 100 - 160 m² |
| Fuel | Wood pellets |
| Subject | Action |
|---|---|
| How to clean a Kepo pellet boiler faq | View |
| How to replace the igniter of a Kepo pellet boiler faq | View |
| ER01 - Safety thermostat HV1 intervention Error code | View |
| ER02 - Safety pressure switch HV2 intervention Error code | View |
| ER03 - Shutdown due to decrease in flue gas temperature Error code | View |
| ER04 - Shutdown due to water overtemperature Error code | View |
| ER05 - Shutdown due to flue gas overtemperature Error code | View |
| ER07 - No encoder signal from combustion fan Error code | View |
| ER08 - Combustion fan speed regulation failed Error code | View |
| ER09 - Low water pressure Error code | View |
| ER10 - High water pressure Error code | View |
| ER11 - Incorrect time/date values after long absence of mains power Error code | View |
| ER12 - Ignition failed Error code | View |
| ER15 - Power supply fault Error code | View |
| ER16 - RS485 communication error Error code | View |
| ER17 - Air flow regulation failed Error code | View |
| ER18 - Lack of fuel Error code | View |
| ER23 - Boiler probe, boiler return probe, buffer tank probe, or low buffer tank probe open Error code | View |
| ER25 - Cleaning motor fault Error code | View |
| ER26 - Cleaning motor 2 fault Error code | View |
| ER27 - Cleaning motor 3 fault Error code | View |
| ER39 - Flowmeter sensor fault Error code | View |
| ER41 - Minimum air flow in Check Up not reached Error code | View |
| ER42 - Maximum air flow exceeded (FL40) Error code | View |
| ER44 - Door error Error code | View |
| ER47 - No encoder signal from auger Error code | View |
| ER48 - Auger speed regulation failed Error code | View |
| ER56 - Modified hydraulic plant Error code | View |
