iGarden InverX7 - iGXC8 - Monobloc Air-to-Water Heat Pump with AI Control (8 kW)
Restricted access
On backorder
Delivery deadline: 20 - 30 werkdagen
The iGarden InverX7 iGXC8 is a modulating R290 air-to-water heat pump with a nominal output of 8 kW. This single-phase monobloc heat pump supports heating, active cooling and control of an external domestic-hot-water cylinder. With A+++ at 35 °C and 55 °C, a maximum water temperature of 75 °C and a COP of up to 7, the InverX7 combines high efficiency with intelligent control and a distinctive design.
Read more
Other variants
Our partner network
iGarden Certified Partners
For homeowners
Let an iGarden Certified Partner contact you
Share your details. Hewa reviews your request and selectively connects you with a suitable iGarden Certified Partner in your region.
For installers
Become an iGarden Certified Partner?
Get direct access to the iGarden range, personal partner support and professional purchasing terms.
- 220-240 V - 50 Hz - single phase
- A+++ at 35 °C and 55 °C
- COP of up to 7 under defined test conditions
- Sound-pressure level of 43 dB(A) at 1 metre
- 5-year warranty on other components
- 7-year compressor warranty
iGarden InverX7 iGXC8 8 kW AI heat pump
The iGarden InverX7 iGXC8 is an intelligent R290 air-to-water heat pump with a nominal heating output of 8 kW. This monobloc heat pump combines AI-controlled modulating inverter technology with high efficiency, quiet operation and a maximum water temperature of 75 °C. The iGXC8 supports heating, active cooling and control of an external domestic-hot-water cylinder.
The complete refrigerant circuit is contained within the outdoor unit and uses the natural R290 refrigerant. The heat pump is connected hydraulically to the heating system and operates from a 220-240 V single-phase power supply. View the other heat pumps available from Hewa.
AI-controlled inverter technology
One of the key features of the InverX7 is its intelligent control system. The controller continuously processes current operating and temperature data and adjusts inverter output accordingly. This allows the heat pump to respond accurately to changes in heating demand without continuously operating at maximum capacity.
Modulating operation supports stable indoor temperatures, reduces unnecessary switching and contributes to efficient and quiet system operation.
According to the technical product data, the heating-capacity range of the iGXC8 is 2.11 to 10.04 kW. Its COP range is 4.13 to a maximum of 7.00. Actual performance depends on factors including outdoor temperature, required water temperature and hydraulic system design.
A+++ at both 35 °C and 55 °C
The iGarden InverX7 iGXC8 achieves an A+++ energy rating at a water temperature of both 35 °C and 55 °C. This makes the heat pump suitable for modern low-temperature systems as well as correctly designed renovation applications.
The maximum outlet-water temperature is 75 °C. The InverX7 can be combined with underfloor heating, low-temperature radiators, fan coils and other correctly sized heat-emission systems.
Heating, active cooling and domestic hot water
In addition to space heating, the InverX7 supports active cooling and can control a suitable external domestic-hot-water cylinder. It can therefore form the basis of a complete year-round climate system.
- Space heating
- Active cooling
- External domestic-hot-water cylinder control
- Weather-compensated control
- Wi-Fi operation and monitoring
- SG Ready
- PV Ready
Ready for intelligent energy management
With SG Ready and PV Ready support, the InverX7 can be integrated into modern energy systems. External control signals and available photovoltaic energy can be incorporated into the heat pump's operating strategy.
The intelligent control platform therefore provides a foundation not only for efficient heating and cooling, but also for future energy systems in which heat pumps, solar power and energy management increasingly operate together.
Hydraulic system design
Stable and efficient operation requires sufficient system-water volume and a correctly sized heat-emission system. Depending on the installation, a suitable buffer tank can be used.
The nominal water-flow requirement of the iGXC8 is 1.50 m³/h. The water connections are G1". Pipe dimensions, circulation, frost protection, condensate drainage and system-water volume must be matched to the individual installation.
Hewa also supplies valves, pumps, expansion vessels, separators and other components required for the hydraulic installation within its range of heating connection materials.
Quiet operation and distinctive design
According to the technical product data, the iGXC8 has a sound-pressure level of 43 dB(A) at one metre and 29 dB(A) at three metres. Actual sound levels depend on factors including installation position, foundation, airflow, vibration isolation and distance from surrounding buildings.
The glass front, integrated lighting and aluminium casing also give the InverX7 a distinctive premium appearance compared with conventional heat-pump outdoor units.
Warranty and support through Hewa
The iGarden InverX7 is covered by a warranty programme consisting of a 3-year exchange guarantee in case of leaks, 5 years on other components and 7 years on the compressor. The applicable installation, registration, commissioning and maintenance conditions apply.
For more information about the complete product range and support available from Hewa, visit our iGarden page.
| Generals | |
|---|---|
| Item number | 760008 |
| EAN Code | 6973156065978 |
| Sizes ((LxWxH):) | 141,1 x 56 x 81,5 cm |
| Specification list | |
| Heating capacity range (kW) | 2.11-10.04 kW |
| Heating power input range (kW/h) | 0.33-3.01 kW |
| COP range | 4.13 - 7.00 |
| Cooling capacity range (kW) | 1.89-9.15 kW |
| Cooling power input range (kW/h) | 0.47-2.89 kW |
| EER range | 2.21-4.33 |
| ErP level (35°C) | A+++ |
| ErP level (55°C) | A+++ |
| Refrigerant | R290 |
| Power supply | 220-240 V - 50 Hz - 1 F |
| Max. power input (kW/h) | 4.2 kW |
| Max. current (A) | 16 A |
| Minimum fuse or circuit breaker (A) | 16 A |
| Wire diameter (mm²) | 3 x 2.5 mm² |
| Pipe connection size | G1" aanvoer en retour |
| Max. head (m) | 8 m |
| Noise dB (A) | 43 dB(A) at 1 metre / 29 dB(A) at 3 metres |
| Net weight (kg) | 100 |
| Dimension (W×D×H) mm | 1411 x 56 x 815 |
| Operation ambient temperature (°C) | -25 tot +43 °C |
| Operating water temperature heating (°C) | 20 tot 75 °C |
| Operating water temperature cooling (°C) | 7 tot 25 °C |
| Operating water temperature domestic hot water (°C) | 20 tot 75 °C |
