Mikoterm mTronic 7000 - Electric boiler (24 kW)
Price excl. VAT€ 933,84Price incl. VAT€ 1.129,95
Op nalevering
The Mikoterm mTronic 7000 (24 kW) is an electric boiler with 2.7 kW step control, 12.5-litre tank and CPU safety system. Perfect for hybrid heating in large-scale projects.
Read more
Other variants
- 24 kW output for large residential, commercial and industrial projects
- Not approved as primary heating under efficiency regulations
- 2.7 kW step control for precise load adjustment
- 12.5-litre tank with complete integrated equipment
- Four-level CPU safety system with full protection
- Quiet operation thanks to silent relays
- Hybrid-compatible with heat pumps, solar and PV systems
High-capacity electric heating solution
The Mikoterm mTronic 7000 - Electric boiler (24 kW) is the most powerful model in this range. With its high output, it is designed for large homes, commercial facilities and industrial applications.
Not approved as main heating system
According to efficiency regulations, an electric boiler like the mTronic 7000 cannot be used as the primary heating system in residential buildings. It does not meet the required standards for seasonal efficiency. In practice, the 24 kW model is used as a hybrid or auxiliary solution, combined with a heat pump, solar water heater or PV systems.
2.7 kW step control for flexible output
This model features 2.7 kW step control, allowing the heating capacity to be adjusted precisely to demand. This ensures efficient operation and reliable performance in larger installations.
Fully equipped for immediate use
The mTronic 7000 (24 kW) includes a 12.5-litre tank, A-label pump, expansion vessel, safety valve and overpressure valve. Ready to integrate directly into existing systems.
Safe and quiet operation
The CPU controller provides four levels of safety, including a complete shutdown in case of critical faults. Silent relays ensure low-noise performance, even under continuous load.
Hybrid-ready for large-scale projects
The mTronic 7000 (24 kW) can control an indirect hot water cylinder and combine with a buffer tank or hot water cylinder, making it ideal for hybrid systems in large buildings.
Support from Hewa
Hewa supplies the Mikoterm mTronic 7000 - Electric boiler (24 kW) from stock and provides installers with technical documentation, expert advice and fast delivery.
| Generals | |
|---|---|
| Item number | 380124 |
| EAN Code | 8721082877824 |
| Price excl. VAT | € 933,84 |
| Price incl. VAT | € 1.129,95 |
| Sizes ((LxWxH):) | 23 x 43 x 71 cm |
| Specification list | |
| Power (kW) | 24 kW |
| Power efficiency (%) | 99 % |
| Number of elements | 9 |
| Power distribution (kW) | 9 x 2.7 kW |
| Power supply | 3N ~ 400VDC 50Hz |
| Protection level | IP40 |
| Fuses required for three-phase supply (A) | 3 x 40 A |
| Minimum cross-section of three-phase cable (mm²) | 5 x 6 mm² |
| Safety valve (bar) | 3 bar |
| Min. allowable operating pressure (bar) | 0.3 bar |
| Max. allowable operating pressure (bar) | 2.6 bar |
| Temperature range (°C) | 10 - 80 °C |
| Safety thermostat (°C) | 95 °C |
| Water volume in boiler (L) | 12.5 L |
| Expansion vessel (L) | 8 L |
| Water pipe connection size | G 3/4" M |
| Weight (kg) | 25 kg |
| Dimension (W×D×H) mm | 430x230x710 mm |
| Processor unit | EK_CPU_1_3 |
