ALPS EXCLUSIVE WKB-HV-200/80L(V2) - Stainless steel combination boiler (200/80L)
Other variants
- 200 litres of tap water + 80 litres of buffer tank in one compact unit
- Made from high-quality SUS316L stainless steel
- Double-walled heat exchanger (2.05 m²) for rapid heat transfer
- Suitable for heating, cooling and domestic hot water
- Space-saving design, ideal for homes and smaller systems
Compact total solution for heat and hot water
Are you looking for a solution that provides both hot tap water and buffer capacity for your heating system without taking up too much space? The ALPS EXCLUSIVE WKB-HV-200/80L(V2) is specially designed for homes and installations where efficient use of space and high performance go hand in hand.
Two functions in one system
Instead of installing separate appliances for tap water and buffer tank, this model combines both functions in one unit. With 200 litres for tap water and 80 litres of buffer capacity, the boiler not only provides a stable hot water supply, but also extends the life of your heating system by preventing unnecessary switching moments.
Efficient heat exchanger
The built-in 2.05 m² heat exchanger ensures fast and energy-efficient heat transfer. Whether you work with heat pumps, solar boiler systems or a conventional central heating system, this system makes optimum use of the available energy and ensures rapid heating of the tap water.
Heating and cooling
Thanks to the thermally separated compartments, the buffer tank can be used not only for heating but also for cooling. If you combine this combination boiler with underfloor heating or surface cooling, you will enjoy a pleasantly cool indoor climate in summer and stable heat output in winter.
Robust materials and insulation
The AE-200/80L(V2) is made of SUS316L stainless steel, which guarantees maximum corrosion resistance and a long service life. The 50 mm thick polyurethane insulation layer minimises heat loss, making the system more efficient and sustainable.
Flexible and future-proof
- Easy installation thanks to strategically placed connections
- Optional electric heating elements for extra capacity or backup
- Pressure-resistant design (up to 8 bar for tap water and 4 bar for buffer tank)
- Designed for integration with both conventional and sustainable energy sources
Who is this model suitable for?
- Homes with limited technical space but high hot water requirements
- Installations where heating and cooling are combined
- Families and small businesses looking for an efficient, sustainable solution
- Projects where space saving and low energy costs are key
Hewa: your partner in smart installations
At Hewa, you benefit from high-quality products, comprehensive technical support and tailored advice. Would you like to know whether the WKB-HV-200/80L(V2) is suitable for your project? Our specialists will be happy to help you determine the right configuration.
The ALPS EXCLUSIVE WKB-HV-200/80L(V2) combination boiler combines tap water comfort and buffer capacity in one compact unit. With its efficient heat exchanger, robust stainless steel construction and versatile application options, this model is a smart investment for those who want to combine comfort, efficiency and sustainability in a space-saving design.
| Generals | |
|---|---|
| Item number | 394228 |
| EAN Code | 8721082877978 |
| Price excl. VAT | € 1.486,78 |
| Price incl. VAT | € 1.799,00 |
| Sizes ((LxWxH):) | 58 x 58 x 184 cm |
| Specification list | |
| Volume | 200L DHW 80L BT |
| Diameter | 580 mm |
| Height | 1840 mm |
| Inner tank material | SUS 316L |
| Insulation layer thickness | 50 mm |
| Insulation | Polyurethane |
| Working pressure buffer tank | 4 bar |
| Working pressure DHW tank | 4 bar / 6 bar |
| Empty weight | 72 kg |
| Circulation 1 inlet | G 1 1/2" F |
| Circulation 1 outlet | G 1 1/2" F |
| Circulation 2 inlet | G 1 1/2" F |
| Circulation 2 outlet | G 1 1/2" F |
| Circulation 3 inlet | G 1 1/2" F |
| Circulation 3 outlet | G 1 1/2" F |
| Temperaturesensor port | DN 15 / 1/2" G F | Prepared immersion tube |
| Drain | G 3/4" F |
| Air vent | G 1/2" F |
| Heat exchanger inlet | G 1" F |
| Heat exchanger outlet | G 1" F |
| Electric (backup) heater | G 1 1/2" F |
| Domestic hot water outlet | G 3/4" F |
| Domestic cold water inlet | G 3/4" F |
| Magnesium port | G 3/4" F |
| Pressure valve | G 3/4" F |
| Drain | G 3/4" F |
| Heat exchanger material | SUS 316L |
| Heat exchanger length | 26 m (25 mm) |
| Heat exchanger surface area | 2.05 m2 |
| Recirculation port | G 3/4" F |
| Inhoud | 200/80L |
