Chico - PW58200 - circuit board

Chico PW58200 circuit board

The Chico PW58200 is a circuit board for the electronic control of a compatible inverter heat pump. The circuit board is used as a drive board within the inverter system and plays an important role in compressor control.

The PW58200 electronically controls the compressor and regulates compressor output according to heat demand and signals from the heat pump control system.

Product information

• Brand: Chico
• Circuit board code: PW58200
• Component: circuit board / drive board
• Supplier part number: 802002-2615
• Application: inverter heat pump

Application

The PW58200 is listed as a spare part for the PW040-DKZLRS-A heat pump. This system uses an inverter compressor.

This does not automatically mean that every PW58200 version is interchangeable. Always check the existing circuit board and the heat pump rating plate before ordering.

Check before ordering

Compare the PW58200 designation with the existing circuit board before ordering. Also check the electrical connections, any revision markings and the exact heat pump model.

Circuit boards may look very similar while using different electronics, software or control configurations.

Need help selecting the correct circuit board?

If you are unsure whether the PW58200 is suitable for your heat pump, send us a clear photo of the heat pump rating plate and the existing circuit board. We will be happy to help you identify the correct replacement part.

Installation

We recommend that diagnosis and replacement of the circuit board are carried out by a qualified technician. The heat pump must be completely disconnected from the power supply before any work is carried out on electrical components.
