Mikoterm TK-24 Professional – Industrial electric boilers from 40 to 240 kW
Mikoterm TK-24 Professional – Industrial electric boilers from 40 to 240 kW
In commercial heating systems and industrial installations, the demand for high-capacity electric heat generators is increasing. Electric boilers are often used as a backup heat source, peak load solution, or as part of fully electric heating concepts.
The Mikoterm TK-24 Professional series is specifically designed for professional installations where reliability, precise capacity control and system integration are essential. These industrial electric boilers are available with outputs from 40 kW up to 240 kW and are widely used in commercial buildings, industrial facilities and hybrid heating systems.
Typical applications in commercial and industrial systems
Electric boilers in this capacity range are typically used in large-scale installations rather than residential systems. They are designed for buildings where high heating output and stable system temperatures are required.
- Peak load support in heat pump installations
- Backup heating for critical systems
- Temporary heating during renovation projects
- Fully electric heating systems in gas-free buildings
- Industrial process heating
- Support for low-temperature heating networks
Technical features of the Mikoterm TK-24 Professional
The TK-24 Professional series is designed for engineers and installers working on large heating installations. The modular heating control allows the system to adapt its output precisely to the required heat demand.
- Output range: 40 kW to 240 kW
- Modular power control with staged heating groups
- Temperature range: adjustable from 10 °C to 90 °C
- Versions available: 4 bar and 6 bar operating pressure
- Industrial construction for continuous operation
- Control system: microprocessor controller with LCD display
The choice between the 4 bar and 6 bar version depends on the hydraulic design of the heating installation. Standard commercial systems usually apply the 4 bar version, while the 6 bar version is suitable for systems with higher static pressure.
Building management system integration
The TK-24 Professional supports communication via RS Modbus and RS485 RTU, allowing seamless integration with building management systems.
- Operating status monitoring
- Temperature and setpoint control
- Alarm and fault notifications
- Energy monitoring and system diagnostics
Installation requirements
Installing electric boilers in this capacity class requires proper electrical and hydraulic system design.
- Three-phase 400V electrical connection
- Properly sized distribution panel
- Electrical cabling according to regulations
- Hydraulically balanced heating system
- Correctly sized expansion vessels
- Water treatment according to VDI 2035
Typical project environments
- Hospitals and healthcare facilities
- Educational buildings
- Industrial production facilities
- Logistics warehouses
- Large commercial buildings
